Northwood CS265 Twin-Table CNC Router - 2014!

• Northwood CS265 Twin-Table CNC Router - 2014!
• Located at RT's Hughesville Facility
• One 18 HP "Cartridge" Spindle, Programmable up to 24,000 RPM
• Router Spindle Accepts HSK F63 Chucks
• Router Spindle Includes Spindle Aggregate Retention Ring
• One Twelve-Position Carousel-Style Automatic Tool-Changer
• Three Dedicated 21-Spindle L-Shaped Flexible Drilling Units, Each with Thirteen Vertical Spindles (5 x 8) and Four double-ended horizontal spindles (2 x 4)
• Tool Touch Probe
• Spoil Board Milling Software
• One 40 HP Vacuum Pump
• Two 76" x 61" Cast Aluminum Vacuum Worktables
• Remote Operator Pedestal
• Ten Steel External Part Location Pins
• Eight Internal Part Location Pins
• Fanuc OiMD CNC Controller w/ Windows 7, 10.4" Color LCD Touch-Screen
• Axes X, Y, & Z are all Driven by Fanuc AC Servos Powering Precision Ground Ballscrews
• Z-Axis Travel: 14"
• 2014 Machine
• 480v, 3ph
• Serial #: 10393
