Northtech Model iDovetail24

Machine Available
Stock #21827N
New
   CALL FOR PRICE

  • Northtech Model iDovetail24
  • 4.2kw (6HP) driven spindle
  • Programmable spindle controls with a maximum 24,000RPM
  • Maximum processing width: 610mm (24")
  • Tenon dimensions: See following profile mode specific details
  • Workable part dimensions: See following profile mode specific details
  • Spindle vertical adjustment: 100mm (4") servo positioned
  • Usable bits: See following detail
  • Recommend working pneumatics: 90PSI on a 3/8" air line
  • 200 Programmable profile memory
  • Dust port (2) 4" requiring 436CFM @ point of extraction
  • 195in/min dovetail bit acceleration
  • Bit sharpening compensation adjustments via touchscreen interface
  • Automatic bit recognition
  • Horizontal & Vertical pneumatic clamping allows individual part release and mitered profiles
  • Easy to understand error detection and display
