Automated Lumber Handling Grading and Stacking Line with Bin Sorter
Machine Available
Stock #44621
Used- Automated Lumber Handling Grading Line with Bin Sorter and Stacker
- Infeed Four (4) Chains 10’ wide x 21’ long
- Bundle Breakup Section Six(6) Chains 15’ Wide X 6’ Long Inclined
- Board Unscrambler Seven(7) Chains
- Even Ender with Six(6) Rolls
- Chain Deck with Seven(7) Chains, Two(2) Board Stops and a Board Dealer
- Singulation Section Seven(7) Chains with Lugs 25’ long. This is the Marking area for Lumber Grader
- Integrated Solutions Scanner to Measure Length and Width of Boards
- Lucidyne Scanner to Read Grade Marks
- Tipple Section for Rejecting Boards. Two(2) Carts for accumulating rejected Boards. Carts are 39” Wide X 12’ Long
- Incline Chains with Lugs to Carry Boards to Bin Sorter
- Thirteen(13) Bay Bin Sorter. Opening Approx. 16” Wide with Hydraulic Tipples to release Boards into Bin. Each Bin has 5 Arms Approx. 12’ Long. The Beam for Indexing Bundles has 5 Arms Approx. 30” Wide
- Chains Section under Bins for Removing Completed Bundles Four(4) Chains Approx 48’ Long
- At the End of the Bin Section there is a Roller Section to Introduce Packs. Rolls 5’ Wide X 18’ Long
- Bundles are Transferred to Incline Chains. Six(6) Chains with Lugs
- Unscrambler Six(6) Chains with Even Ender Rolls at top
- Layer Building Area is 20' long with Seven(7) Roof Top Chains
- Blades Between Chains to Transfer a Layer of Boards to the Stacker
- Stacker has Nine(9) Slots for Stick Laying
- Stacker Section 5’ Wide X 5’ High with 54” Wide Rolls
- Outfeed Rolls are 58” Wide X 35’ Long
- Lumber Packs are then Transferred to a Three(3) Strand Package Chain Section for Removal, 21’ Long
