Timesavers Model 3331-25-001 Three Head 52" High Production Widebelt
Machine Available
Stock #71410N
New- Timesavers Model 3331-25-001 Three Head 52" High Production Widebelt Sander
- Specifications:
- Abrasive belt size: 52" x 75"
- Main motor: 40, 30, 30 HP
- Maximum width stock: 51"
- Minimum part length: 21.5"
- Maximum thickness opening: 6"
- Indeed Loading Area: 30"
- Feed speed: 15-45 FPM
- Passline height: 32-38"
- Dust extraction: 5480 CFM (5” static pressure)
- 6 CFM @ 90 psi
- Standard Features:
- Drum Heads: (first and second head positions)
- Dual Action Sanding Head: (third head position)
- 40, 30 & 30 Horsepower Main Drive Motors
- Infeed Stop Bar
- Infeed Roller Table
- Holddown Shoes and Rolls
- Air Operated Disc Brakes
- Centralized Control Panel
- Dial Indicators on Adjustable Drum/Platen Heads
- Air Pop Up on Drums/Platens
- Quick Release Outboard Support
- Main Motor Percentage Load Meter
- Hour Meter
- Four Jack Bed Construction
- Motorized Thickness Adjustment
- Electronic Go-To Device
- Variable Speed Conveyor Drive
- Through-Beam Abrasive Belt Tracking
- U.L. Listed Components
- Factory Start-up and Training
